Engine Information
EPA certificated
Engine type:

4-stroke, single cylinder, air cooled
Displacement:

169cc
Max HP:

8.2hp/7500rpm
Max torque:

7 lb ft/6000rpm
Bore x stroke:

2.26×2.28 inches
Max speed:

43.5 mph
Climbing ability:

12 degrees
Ignition:

C.D.I
Starting system:

Electric
Battery:

12V 10Ah
Carburetor brand:

Deli (Vacuum film)
Engine oil:

SAE 15W-40
General Information
Clutch:

Automatic CTV with reverse
Driveline / Driving wheel:

Chain / Dual wheel drive
Suspension, F / R:

Double A-arm / swing-arm
Brakes, F / R:

Both hydraulic brakes, Disc
Tires, F / R:

20×7-8 / 22×10-10
Wheel:

Aluminum
Fuel capacity:

2.25 gal
Weight, G.W. / N.W.:

573 / 485 lbs
Max load:

500 lbs
Dimension Information
Wheelbase:

59 inches
OA L x W x H:

85×53.1×57.5 inches
Height to seat:

13.8 inches
Min ground clearance:

6.7 inches
Pedal to seat back distance:

39” to 43”
Key features:
Polished Aluminum wheel

Digital speedometer/odometer
Top hunting lights

Aluminum side mirrors
Turn signals

Sporting steering wheel
Electric start with kill switch

Fully automatic with reverse, high performance GY6 engine with internal reverse set up
Adjustable steering wheel

Large tires with 20X7-8 in the front and 22X10-10 in the back
Four-point safety seatbelt

Individual sporting seats
Polished stainless steel muffler

High-low beam head light
Bikini sunshade top

Adjustable driver seat: pedal to seat back adjustable from 39” to 43”
Central rear view mirror

Heavy duty front and rear shock absorber
Rack and pinion steering wheel

Front and rear hydraulic disc brake
4-point rear swing arm

Parking brake
4-wheel fenders

Trailer hitch
Large rear utility rack

Large gas tank
